Oxygen Transmission Rate Analyser

Applications

• Film and Foils Testing, Package Testing, Plastic Testing, Blister Pack Testing, Rubber Testing


Test Property

• Oxygen Transmission Rate, Oxygen Permeability


Test Method

• Equal pressure method (coulometric sensor method)


Standards

• ASTM D3985, ASTM F2622, ASTM F1307, ISO 15105-2, and ASTM F1927


• Wide range and high precision of temperature and humidity control
• Patent design of three diffusion cells integrated in one instrument for individual or multiple tests
• Can be easily connected with 9 satellite bases together to accomplish up to 30 tests at the same time
• Reference film


• Test range: 0.01~65,000 cm3/m2

• Resolution: 0.001 cm3/m2

• Temperature range: 15^oC~55^oC
• Humidity range: 0%RH, 35%RH~90%RH, 100%RH


• 690 mm (L) x 350 mm (W) x 360 mm (H)
• Net weight: 70kg


• Catalog number: OX2/230
• Optional Parts: Sample Cutter, Accessories for package test, etc.
