Gelbo Flex Durability Tester

Gelbo Flex Durability Tester

2000.00 - 20000.00 USD ($)/Set

Product Details:

  • Machine Weight 12kg Kilograms (kg)
  • Supply Ability : 10 Set Per Month
  • Click to view more
X

Price And Quantity

  • 1 Set
  • 2000.00 - 20000.00 USD ($)/Set

Product Specifications

  • 12kg Kilograms (kg)

Trade Information

  • Jinan
  • 10 Set Per Month
  • 7 Days
  • Standard Veneer Case
  • All India
  • ISO 9001, CE

Product Description

FDT-02 Gelbo Flex Durability Tester can simulate the kneading and creasing behaviors of films happened during production, processing and transportation, by which the flex durability of samples can be determined.

Standards:ASTM F392

Applications:

  • Flexible Films, Composite Films and Coating Films
  • Paper Material

Features:

  • 5 standard test modes and 4 specimen stations support various combinations of non-standard test conditions.
  • Quick switch between long and short strokes improves the test efficiency.
  • Application of servo motor further ensures the accuracy of test results.
  • Dual protection for hardware and software as well as auto reset provides a safe operating environment for customers
Technical Specification

Specifications

FDT-02 Gelbo Flex Durability Tester

Flex Frequency

45 /minute

Tensile & Pressing Force

300 N

Torque

2 Nm

Specimen Thickness

2.5mm (Sample clamps are needed for other thickness specimen)

Flex Angle

440° or 400°

Horizontal Stroke

155 mm or 80 mm

Number of Stations

4

Number of Specimens

1 ~ 4Note

Specimen Size

280 mm x 200 mm

Instrument Dimension

715 mm (L) x 415 mm (W) x 645 mm (H)

Net Weight

85 kg



LABTHINK INSTRUMENTS CO. LTD.
