C870H Integrated Loss-on-Drying Testing System
80000.0 USD ($)/Unit
Product Details:
- Display Type 7-inch Color LCD Touchscreen
- Gas Pressure 0.4-0.6 MPa
- Temperature Ambient to 250C
- Operating Voltage AC 220V/110V, 50/60Hz
- Test Range 0-100% (Moisture Content)
- Frequency 50/60Hz
- Interface Type USB, RS232
- Click to View more
X
C870H Integrated Loss-on-Drying Testing System Price And Quantity
- 1 Unit
- 80000.0 USD ($)/Unit
C870H Integrated Loss-on-Drying Testing System Product Specifications
- Approx. 75 kg
- 7-inch Color LCD Touchscreen
- Ambient to 250C
- 0.4-0.6 MPa
- 50/60Hz
- AC 220V/110V, 50/60Hz
- 0-100% (Moisture Content)
- 5 kg
- USB, RS232
- Standard 1/2 inch
- Integrated Loss-on-Drying Testing System
- 450 mm
- Loss-on-drying, moisture, and volatility analysis
- Up to 100 x 100 mm
- 0.01g
- 2 seconds
- 1-5 at a time
- Adjustable, typically 5-30 mm/min
- Fast Heating, Data Export, Multi-language Support
- Touch Screen, PLC Control
- Automatic
- 0.01-100% moisture
- 220V, 50Hz/60Hz
- 0-150 mm
- Up to 250 mm
- 85% RH
- Bench-top
- Precise Loss-on-Drying Measurement for Lab Use
- 0.01g/0.01%
- Overtemperature/Completion/Abnormal Operation
- Halogen Lamp/Infrared
- Stainless Steel, Corrosion Resistant
- 550 mm x 400 mm x 500 mm
- Built-in memory, >500 sets
- Overload Protection, Overheat Protection
- Internal Calibration
- Built-in Fan
- Windows/Android Data Management
Product Description
C870H Integrated Loss-on-Drying Testing system is based on the gravimetric method and is designed and manufactured in accordance with pharmacopoeias and testing standards of the food and chemical industries. It is professionally suitable for loss-on-drying testing in the above-mentioned fields.Advanced Moisture Analysis Technology
Harnessing dual heating options of halogen lamp and infrared, the C870H delivers swift and precise loss-on-drying, moisture, and volatility determination. Its rapid response time and adjustable test speed help laboratories increase throughput without compromising accuracy. The 7-inch color LCD touchscreen interface improves usability, offering intuitive control, real-time data visualization, and multi-language support for global laboratories.
Dependable Safety and Efficient Operation
Engineered with comprehensive safety measures such as overload and overheat protection, and a built-in cooling fan, the C870H ensures both user safety and equipment longevity. Its stainless steel sample pan resists corrosion, maintaining measurement integrity. The overtemperature, completion, and abnormal operation alarms provide additional security, making it ideal for routine and demanding laboratory workflows.
Data Handling and Seamless Integration
The C870H streamlines laboratory data management with its large built-in memory for over 500 sets, USB and RS232 connectivity, and compatibility with both Windows and Android platforms. Data export functions enable efficient record-keeping and integration with laboratory information management systems, facilitating traceability, compliance, and reporting requirements.
FAQ's of C870H Integrated Loss-on-Drying Testing System:
Q: How does the C870H Integrated Loss-on-Drying Testing System achieve precise moisture measurement?
A: The C870H employs halogen lamp and infrared heating to evenly and efficiently remove moisture from samples. Its internal calibration system, combined with high accuracy (0.01g/0.01%), ensures precise measurement. The automatic operation and touch screen control further enhance repeatability and reliability in moisture content determination.Q: What types of samples and applications is the C870H suitable for?
A: This system is ideal for laboratories conducting loss-on-drying, moisture, and volatility analysis. It accommodates specimens up to 100 x 100 mm, weighing up to 5 kg, and can analyze a moisture content range of 0.01-100%. It is widely used for quality control, research, and product development across various industries.Q: When is it advisable to use the built-in alarm and safety features?
A: The built-in alarms for overtemperature, completion, and abnormal operation activate as needed during the testing process. Overload and overheat protections are continuously active, ensuring both safety and equipment durability during all operations, especially with prolonged or high-capacity testing.Q: Where can data from the C870H be stored and managed?
A: Data can be stored directly on the instrument's built-in memory (capable of holding over 500 sets), and exported using USB and RS232 interfaces. The system is compatible with both Windows and Android platforms, enabling seamless data management and integration with other laboratory systems.Q: What does the testing process involve in the C870H system?
A: Samples are placed on the corrosion-resistant stainless steel pan and testing is initiated via the intuitive 7-inch LCD touchscreen. The instrument then heats the sample using selectable methods, measures loss-on-drying over a user-defined duration, and calculates moisture content. Results are available rapidly, with options to export and store data.Q: How does using the C870H system benefit laboratory operations?
A: The C870H provides fast, accurate moisture analysis with minimal user intervention, increasing laboratory throughput and consistency. Its versatility, ease of operation, and comprehensive data management capabilities reduce manual errors while supporting compliance and traceability requirements.Tell us about your requirement
