C870M Integrated Loss-on-Drying (LOD) Testing System
30000.0 USD ($)/Unit
Product Details:
- Equipment Type Integrated Loss-on-Drying (LOD) Testing System
- Mounting Type Benchtop
- Interface Type USB, RS232
- Temperature Room Temperature to 250C
- Display Type 7-inch Color Touch Screen
- Gas Pressure 0.5~0.8 MPa
- Response Time 1 sec
- Click to View more
X
C870M Integrated Loss-on-Drying (LOD) Testing System Price And Quantity
- 1 Unit
- 30000.0 USD ($)/Unit
C870M Integrated Loss-on-Drying (LOD) Testing System Product Specifications
- 7-inch Color Touch Screen
- Microprocessor-based Touch Screen
- Room Temperature to 250C
- 80 mm
- 1 sec
- Integrated testing, high precision, user-friendly interface
- 120 mm
- 0.5~0.8 MPa
- Laboratory, QC
- Varies by mode (Multi-sample)
- USB, RS232
- Integrated Loss-on-Drying (LOD) Testing System
- Benchtop
- AC 220V, 50 Hz
- Moisture/volatiles determination in solids, powders, granules
- Approx. 50 kg
- 0.001 g
- Standard Gas Inlet 1/4 inch
- Configurable, 1-10 cycles/min
- Fully Automatic
- 350 mm
- 0.01g to 100g
- 50 Hz
- 0.001 g
- 10~90% RH (Non-condensing)
- 220V 10%
- 0.01~100 g
- 1~3
- Max 120 x 80 mm
- Online via USB or LAN
- Internal memory (up to 1,000 test results)
- LAN connectivity, printer support
- <5W
- Halogen infrared lamp
- Automatic & manual
- ISO 9001, CE Certified
- 10~40C, max 85% RH
- Overheat protection, password access
Product Description
C870M Integrated Loss-on-Drying Testing System is based on the gravimetric method and is designed and manufactured in accordance with pharmacopoeias and testing standards of the food and chemical industries. It is suitable for loss-on-drying testing in the above-mentioned fields.Advanced Moisture Determination Technology
Equipped with a halogen infrared lamp, the C870M Integrated LOD Testing System enables fast and uniform heating, ensuring precise moisture and volatile analysis. Its microprocessor-based control and high-resolution sensor (0.001 g accuracy) produce reliable results for a variety of sample types, including solids, powders, and granules.
User-Friendly Interface and Data Management
The system's 7-inch color touch screen provides an intuitive experience. Internal memory securely stores up to 1,000 test results, while LAN, USB, and printer connections streamline data handling, software upgrades, and reporting for laboratory and quality control applications.
Safety and Compliance Assured
With features such as overheat protection, password-controlled access, and adherence to ISO 9001 and CE certification standards, the C870M ensures both operator safety and regulatory compliance. Fully automatic calibration options further support consistent, high-precision measurements.
FAQ's of C870M Integrated Loss-on-Drying (LOD) Testing System:
Q: How does the C870M Integrated LOD Testing System determine moisture content in samples?
A: The C870M employs a halogen infrared lamp to rapidly heat samples, causing moisture or volatiles to evaporate. The integrated balance measures weight loss during the process, providing precise quantification of moisture content with 0.001 g accuracy.Q: What types of specimens and sample sizes can the C870M accommodate?
A: The C870M is designed for testing 1 to 3 specimens simultaneously, handling samples up to 120 x 80 mm in dimension and weighing from 0.01 g to 100 g. This versatility allows analysis of solids, powders, and granules in laboratories and quality control settings.Q: When should I calibrate the C870M and which modes are available?
A: Calibration is recommended before initial use or after significant environmental changes. The system offers both automatic and manual calibration modes, ensuring ongoing test accuracy and reliability as per laboratory standards.Q: Where can I access stored data from the C870M?
A: Stored test data is accessible via the touch screen interface. The C870M's internal memory holds up to 1,000 results and supports easy data export through LAN, USB, or printer connectivity, allowing integration with existing laboratory data systems.Q: What is the process for upgrading the device's software?
A: The C870M supports online software upgrades through USB or LAN interfaces. Users can connect the device to a computer or network and follow on-screen instructions to download and install the latest updates, keeping the system up to date with minimal effort.Q: How does the system ensure user and sample safety during operation?
A: Safety is prioritized with overheat protection mechanisms, password access to restrict unauthorized use, and compliance with ISO 9001 and CE certification. These features, combined with sturdy construction, protect both user and samples during testing.Q: What are the key benefits of using the C870M in laboratory or industrial environments?
A: The C870M offers fully automated, high-precision testing with rapid response, multi-sample handling, extensive data management features, and a user-friendly interface. These attributes boost productivity, enable compliance, and streamline moisture and volatile content determination workflows.Tell us about your requirement
