Fogging Test Device for Leather, Fabrics Automotive Interior Materials

Fogging Test Device for Leather, Fabrics Automotive Interior Materials

10000.00 - 130000.00 USD ($)/Set

Product Details:

  • Temperature Room Temperature -150 Celsius (oC)
  • Specimen Size 670 mm (L) x 490 mm (W) x 540 mm (H) Millimeter (mm)
  • Number of Specimens 6
  • Material Automotive Interiors
  • Weight 32kg Kilograms (kg)
  • Usage Fogging Test
  • Click to View more
X

Fogging Test Device for Leather, Fabrics Automotive Interior Materials Price And Quantity

  • 1 Set
  • 10000.00 - 130000.00 USD ($)/Set

Fogging Test Device for Leather, Fabrics Automotive Interior Materials Product Specifications

  • Room Temperature -150 Celsius (oC)
  • 670 mm (L) x 490 mm (W) x 540 mm (H) Millimeter (mm)
  • 32kg Kilograms (kg)
  • 6
  • Fogging Test
  • Automotive Interiors

Fogging Test Device for Leather, Fabrics Automotive Interior Materials Trade Information

  • Jinan
  • 10 Set Per Month
  • 7 Days
  • Standard Veneer Case
  • All India
  • ISO 9001, CE

Product Description

FT-F1 Fogging Test Device is professionally designed for the fogging characteristics evaluation of volatile constituents of decorating materials used in cars and aircrafts, e.g. plastic articles, polyurethane, textiles, leather, adhesives, nonwovens and thermal forming elastomers at high temperature conditions. It also could be used for the fogging phenomenon test of high intensity discharge (HID) headlamps of cars.

Test Procedures

The test sample is placed in a sealed beaker - the inside surface of the cooled beaker cover is either glass (for the photometric method) or aluminum foil (for the gravimetric method). The bottom of the beaker is placed in a controlled temperature oil bath for a specified period of time - typically 3 hours for the photometric method and 16 hours for the gravimetric method. For the photometric method, gloss readings of the glass cover before the test and after conditioning following the test are compared. For the gravimetric method, weights of the test sample and the aluminum foil before the test and immediately after the test are compared.

Test Standards

ISO 6452, DIN 75201, SAE J1756, QB/T 2728, BS EN 14288, PV 3920, PV 3015, ES-X83231, NES M0161, D45 1727, GM 9305P, TSM 0503G

 Test Methods

Gloss Method, Haze Method, Weighing Method

32 kg

Technical Specification

Specifications

FT-F1

Temperature Range of High-Temperature Bath

Room temperature ~ 150°C
(room temperature ~ 200°C is optional)

Temperature Control Accuracy

±0.1°C

Temperature Measuring Accuracy

±0.3°C (100°C)

Temperature Range of Low-Temperature Bath

0 ~ 100°C (at standard atmospheric pressure)

Temperature Control Accuracy

±0.1°C

Number of Stations

6

Size of High-Temperature Bath

670 mm (L) x 490 mm (W) x 540 mm (H)

Size of Low-Temperature Bath

400 mm (L) x 220 mm (W) x 520 mm (H)

Net Weight of High-Temperature Bath

32 kg (except the weight of heat conducting medium)

Net Weight of Low-Temperature Bath

15 kg (except the weight of heat conducting medium)

Power Supply

220VAC 50Hz / 120VAC 60Hz
