Puncture Strength Tester Machine

2000.00 - 20000.00 USD ($)/Set

Get a Price/Quote

Product Details:

Port Size 1/4 inch BSP
Mounting Type Table-top
Frequency 50 Hz
Display Type Digital LCD display
Operating Voltage 220 V
Test Range 01000 N
Response Time Instantaneous (<1s)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Puncture Strength Tester Machine Price And Quantity

Price Range 2000.00 - 20000.00 USD ($)/Set
Minimum Order Quantity 1 Set

Puncture Strength Tester Machine Product Specifications

Response Time Instantaneous (<1s)
Measuring Range 01000 N
Humidity 2090% RH
Automation Grade Semi-automatic
Temperature 1040C
Gas Pressure 0.40.8 MPa
Interface Type USB/RS232 optional
Resolution 0.1 N
Port Size 1/4 inch BSP
Frequency 50 Hz
Mounting Type Table-top
Operating Voltage 220 V
Display Type Digital LCD display
Test Range 01000 N
Number of Specimens 1 per cycle
Equipment Type Puncture Strength Tester
Test Width 300 mm
Usage Laboratory/industrial
Power Supply 220 V AC, 50 Hz
Specimen Size 100 mm x 100 mm (standard)
Max Height 550 mm
Test Stroke 0250 mm
Hardness Industrial grade
Application Testing puncture resistance of paper, cardboard, and packaging materials
Control Mode Digital microprocessor-based
Capacity 1000 N
Machine Weight Approx. 85 kg
Test Speed 100 mm/min adjustable
Accuracy 1% of reading
Features Multiple test modes, programmable parameters

Puncture Strength Tester Machine Trade Information

Supply Ability 10 Set Per Week
Delivery Time 7 Days

Product Description

Technical Specifications

Load Cell Capacity 500 N (standard) 50 N (optional)
Accuracy Better than 0.5% FS
Test Speed 50, 100, 150, 200, 250, 300, 500 mm/min
Stroke 950 mm
Instrument Dimension 450 mm (L) x 450 mm (W) x 1410 mm (H)

Technical Data

Specifications	XLW (PC)
Load Cell Capacity	500 N (standard) 50 N, 100 N, 250 N (optional)
Load Cell Capacity	750 N, 1000N (Customization Available)
Accuracy	0.5% FS
Number of Specimens	1
Test Speed	50, 100, 150, 200, 250, 300, 500 mm/min
Specimen Width	30 mm (Standard Grip)
Specimen Width	50 mm (Optional Grip)
Stroke	950 mm
Instrument Dimension	450 mm (L) x 450 mm (W) x 1410 mm (H)
Power Supply	220VAC 50Hz / 120VAC 60Hz
Net Weight	68 kg

Precision Testing for Diverse Applications

Engineered for precise testing, this puncture strength tester is ideal for evaluating the durability and resistance of packaging materials such as paper and cardboard. With an adjustable test speed and programmable test modes, it ensures comprehensive and repeatable results, making it suitable for manufacturers, exporters, dealers, and industrial laboratories.

Advanced Technology and User Safety

Equipped with a digital microprocessor-based control and a high-precision load cell, the machine guarantees reliable data. Safety is enhanced by an emergency stop button and a safety shield, while the internal memory allows seamless storage of up to 1000 test outcomes. Optional PC software is available for in-depth data analysis.

FAQs of Puncture Strength Tester Machine:

Q: How does the Puncture Strength Tester determine resistance in packaging materials?

A: The machine uses a high-precision load cell and adjustable clamping fixtures to apply a controlled force to the specimen. The force required to puncture the material is measured and displayed on the digital LCD, providing accurate insight into the materials resistance.

Q: What materials and specimen sizes can be tested with this machine?

A: This tester is ideal for paper, cardboard, and various packaging materials. The standard specimen size is 100 mm x 100 mm, and one specimen is tested per cycle.

Q: When should I use the internal memory versus the optional PC software for storing results?

A: Internal memory, capable of holding up to 1000 test results, is suitable for everyday laboratory use or settings where quick access is necessary. For complex analysis and extensive data management, the optional PC software provides enhanced capabilities.

Q: Where can this tester be installed and used?

A: The machines table-top, industrial-grade design is adaptable for both laboratory and industrial environments. It is widely suitable for manufacturers, suppliers, exporters, and research institutions involved in quality control.

Q: What is the process for conducting a puncture test on this machine?

A: To perform a test, place a 100 mm x 100 mm specimen in the adjustable clamp, set required parameters using the digital control, initiate the test cycle, and allow the machine to measure the force until puncture, recording the result internally or via PC software.

Q: How does the tester enhance safety and ensure accurate readings?

A: It incorporates a safety shield and an emergency stop button for operator protection. Readings are consistently accurate within 1% due to its high-precision load cell and digital microprocessor-based control system.

Q: What are the major benefits of using this puncture strength tester for quality control?

A: Key advantages include reliable and repeatable results, high sample throughput, robust construction, programmable testing modes, user-friendly digital interface, and versatile data handling using internal memory or external PC software.
