Mositure Barrier Testing Machine

10000.00 - 130000.00 USD ($)/Set

Get a Price/Quote

Product Details:

Product Type Laboratory use
Application Pacakging materials
Temperature 15~55 (standard) Celsius (oC)
Usage water vapor transmission rate test
Operate Method Automatic
Capacity 0.1~10,000 g/m224h (standard) Kg/hr
Machine Weight 36 kg Kilograms (kg)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mositure Barrier Testing Machine Price And Quantity

Minimum Order Quantity 1 Set
Price Range 10000.00 - 130000.00 USD ($)/Set

Mositure Barrier Testing Machine Product Specifications

Temperature 15~55 (standard) Celsius (oC)
Operate Method Automatic
Capacity 0.1~10,000 g/m224h (standard) Kg/hr
Usage water vapor transmission rate test
Product Type Laboratory use
Application Pacakging materials
Machine Weight 36 kg Kilograms (kg)

Mositure Barrier Testing Machine Trade Information

FOB Port Jinan
Supply Ability 10 Set Per Week
Delivery Time 7 Days
Packaging Details Standard Veneer Case
Main Domestic Market All India
Certifications ISO 9001, CE

Product Description

W3/030 Moisture Barrier Testing Machine is based on the cup method to measure water vapor transmission rate measurement of plastic films, laminated films, sheets as well as various materials used in medical and construction industries.

This instrument conforms to ISO 2528, GB 1037, GB/T 16928, ASTM E96, ASTM D1653, TAPPI T464, DIN 53122-1, JIS Z0208, YBB 00092003

The test can be performanced as follows:

Under a certain test temperature, a constant humidity difference is generated between two sides of the test specimen. The water vapor permeates through the specimen and into the dry side. By measuring the weight changes of the test dish in different time, water vapor transmission rate and other parameters can be obtained.

Technical specification

Test Range	0.1~10,000 g/m²24h (standard)
Number of Specimens	1~3
Accuracy	0.01 g/m²24h
Resolution	0.001 g
Temperature Range	15^oC~55^oC (standard)
Temperature Accuracy	+0.1^oC(standard)
Humidity Range	10%RH~98%RH
Humidity Accuracy	+1%RH
Air Velocity	0.5~2.5 m/s (customization is available)
Test Area	33 cm² X 3
Specimen Thickness	3 mm (customization is available)
Specimen Size	74 mm
Test Chamber Size	15 L
Gas Supply	Air
Gas Supply Pressure	0.6 MPa
Port Size	4 mm PU tubing
Instrument Dimension	695 mm (L) x 555 mm (W) x 390 mm (H)
Power Supply	AC 220V 50Hz
Net Weight	76 kg
