Gas Permeability Tester for Paint Films
10000.00 - 130000.00 USD ($)/Set
Product Details:
- Specimen Size 97 mm Millimeter (mm)
- Gas Pressure 0.4 MPa~0.6 MPa Pa
- Power Supply 120VAC 60Hz
- Number of Specimens 1
- Test Range 0.1~100,000 cm3/m2/24h/0.1MPa
- Temperature Room temperature~50C Celsius (oC)
- Port Size 6 mm PU Tubing
- Click to View more
X
Gas Permeability Tester for Paint Films Price And Quantity
- 1 Set
- 10000.00 - 130000.00 USD ($)/Set
Gas Permeability Tester for Paint Films Product Specifications
- 120VAC 60Hz
- 1
- 0.1~100,000 cm3/m2/24h/0.1MPa
- 76kg Kilograms (kg)
- 6 mm PU Tubing
- Room temperature~50C Celsius (oC)
- micro computer controlled
- 97 mm Millimeter (mm)
- 0.4 MPa~0.6 MPa Pa
Gas Permeability Tester for Paint Films Trade Information
- Jinan
- 10 Set Per Month
- 7 Days
- Standard Veneer Case
- All India
- ISO 9001, CE
Product Description
Gas Permeability Tester for Paint Films is based on the differential pressure method, and is professionally applicable to the determination of gas transmission rate as well as solubility coefficient, diffusion coefficient and permeability coefficient of plastic films, composite films, high barrier materials, sheeting, metal foils, rubber, tires and permeable membranes.
Gas Permeability Tester for Paint Films conforms to the following standards:
ISO 15105-1, ISO 2556, GB/T1038-2000, ASTM D1434, JIS K7126-1, YBB 00082003
Application:
Gas Permeability Tester for Paint Films is applicable to the determination of gas permeability of:
- Films
- Sheeting
- Various Gases
- Biodegradable Films
- Materials for Aerospace Usage
- Paper and Paper Board
- Paint Films
- Soft Tube Materials for Cosmetics
Features:
- Gas transmission rate, solubility coefficient, diffusion coefficient, and permeability coefficient of the specimen could be obtained at one operation
- Professional Gas Permeation Through Polymer Membranes for sale comes with two test modes: proportional mode and standard mode
- Test range could be extended based on user requirements to test materials with high permeability
- High precision temperature control to meet different test conditions
- Test results could be easily obtained even at extreme condition by data fitting function, which could work at any temperature
- The instrument could be used to test poisonous, inflammable, and explosive gases (customization required)
Specification:
| Items | VAC-V1 |
| Vacuum Resolution | 0.1 Pa |
| Accuracy | ±0.1°C |
| Specimen Size | 97 mm |
| Test Gas | O2, N2 and CO2 (outside of supply scope) |
| Power Supply | AC 220V 50Hz |
| Net Weight | 130 kg |
