Water Vapor Permeability Tester for Packaging

Water Vapor Permeability Tester for Packaging
Water Vapor Permeability Tester for Packaging
Send Inquiry
Product Code : W3/060
Brand Name : labthink
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price Range
  • 5000 - 50000 USD ($)
Product Specifications
  • Specimen Size
  • Φ74 mm
  • Humidity
  • 90%RH~70%RH
  • Temperature
  • 15°C~55°C
  • Port Size
  • Φ6 mm PU tubing
  • Test Range
  • 0.1~10,000 g/m2/24h
  • Number of Specimens
  • 1-6
  • Power Supply
  • 220VAC 50Hz / 120VAC 60Hz
  • Gas Pressure
  • 0.6 MPa
  • Dimensions
  • 660 mm (L) x 480 mm (W) x 525 mm (H)
  • Usage
  • Water Vapor Transmission Rate Testing
  • Machine Weight
  • 70kg
  • Control Mode
  • Micro Computer Controlled
Product Description

Labthink manufactures and exports Professional, High Efficiency and Intelligent Water Vapor Permeability Tester, which is based on the cup method, and is professionally applicable to the water vapor permeability test of film specimens.

Principle

Under a certain test temperature, a constant humidity difference is generated between two sides of the test specimen. The water vapor permeates through the specimen and into the dry side. By measuring the weight changes of the test dish in different time, water vapor transmission rate and other parameters can be obtained


Standards

This Water Vapor Permeability Tester conforms to the following standards:
ISO 2528, GB 1037, GB/T 16928, ASTM E96, ASTM D1653, TAPPI T464, DIN 53122-1, JIS Z0208, YBB 00092003

Features

Convenient fast-access calibration ports for temperature and humidity. Wide range and high-precision of automatic temperature and humidity control to support various combinations of non-standard test conditions.

Technical Specifications

Test Range

0.1~10,000 g/m2·24h (standard)

Number of Specimens

1~6 with independent test results

Accuracy

0.01 g/m2·24h

Resolution

0.0001 g

Temperature Range

15°C~55°C (standard)

Temperature Accuracy

±0.1°C(standard)

Humidity Range

10%RH~98%RH (standard is 90%RH)

Humidity Accuracy

±1%RH

Air Velocity

0.5~2.5 m/s (customization available)

Specimen Thickness

¤3 mm (customization is available for other thickness)

Trade Information
  • FOB Port
  • Jinan
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 7 Days
  • Packaging Details
  • Standard Veneer Case
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, CE
