Seal Strength Analyzer

Product Description

Technical Specifications

Specifications	XLW (M)
Load Cell Capacity	100 N, 200 N, 500 N (one of them is available)
Accuracy	1% FS
Test Speed	50, 100, 150, 200, 250, 300, 500 mm/min
Number of Specimens	1
Specimen Width	30 mm (Standard Grip) 50 mm (Optional Grip)
Clamping Way	Pneumatic Specimen Clamp
Stroke	600 mm
Pressure of Gas Supply	0.5 MPa~0.7 MPa (outside of supply scope)
Port Size	4 mm PU Tubing
Instrument Dimension	450 mm (L) x 580 mm (W) x 1100 mm (H)
Power Supply	AC 220V 50Hz
Net Weight	60 kg

Superior Accuracy and Compliance

Engineered for precision, the Seal Strength Analyzer delivers results with 1% accuracy, fully complying with international standards like ASTM F88 and ISO 11607-1. Its factory calibration ensures reliability, while user calibration options allow for ongoing assurance of measurement integrity. This makes it suitable for quality control labs, packaging manufacturers, and other industrial sectors demanding traceable performance.


Advanced Interface and Safety

Featuring a 7-inch digital touchscreen, the analyzer offers seamless navigation and parameter adjustment. The digital control system enables operators to choose test speeds and sealing widths, while interchangeable fixtures accommodate various samples. Safety is elevated by built-in overload protection and an emergency stop button, ensuring secure operation during testing procedures even in high-volume settings.
