Vacuum Leak Tester for Plastic PET Bottles

Vacuum Leak Tester for Plastic PET Bottles
Send Inquiry
Product Code : MFY-01
Price And Quantity
  • Minimum Order Quantity
  • 1 Set
  • Price Range
  • 2000.00 - 20000.00 USD ($)/Set
Product Specifications
  • Test Material
  • Packages
  • Number of Specimens
  • 1
  • Test Range
  • 0- -90KPa
  • Type
  • Electronic
  • Use
  • Gross Leak Testing
  • Test Medium
  • water
  • Net Weight
  • 12kg Kilograms (kg)
  • Port Size
  • –§6 mm PU Tubing
  • Operating Mode
  • Automated
Product Description

Leveraging on our vast industry experience, we are providing excellent quality Leak Tester that is highly demanded in the market. Offered tester is used to determine gross leak status of food packages, medical packages, bags, pouches, PET bottles and vacuum packages. Further, this tester is manufactured by our adept professionals and is also tested on defined parameters to ensure its excellent quality. We offer this Leak Tester in several technical specifications at the most reasonable price.

Features:

  • Robust construction
  • Precise operation
  • Less maintenance
  • Prolonged service life

Principle

Firstly submerge the specimen in the water within the vacuum chamber, and then evacuate the vacuum chamber to form differential pressure between the inside and outside of specimen. The leakage property could be obtained by observing the steady progression of bubbles from the specimen and how the specimen expands and restores to its original shape after vacuum release.

Standards

This Vacuum Leak Tester conforms to the standards: GB/T 15171, ASTM D3078

Technical Specifications

Specifications

MFY-01

Vacuum Degree

0 ~ -90 KPa

Accuracy

1% FS

Vacuum Chamber Effective Sizes

270 mm x 210 mm (H) (standard)

360 mm x 585 mm (H) (optional)

460 mm x 330 mm (H) (optional)

Note: customization is available for other sizes

Gas Supply Pressure

0.7 MPa (outside of supply scope)

Port Size

6 mm PU Tubing

Instrument Dimension

300 mm (L) x 380 mm (W) x 450 mm (H)

Power Supply

AC 220V  50Hz

Net Weight

12 kg



Trade Information
  • FOB Port
  • Jinan
  • Supply Ability
  • 10 Set Per Month
  • Delivery Time
  • 7 Days
  • Packaging Details
  • Standard Veneer Case
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, CE
