Medical and Pharmaceutical Package Blister Leak Tester

Medical and Pharmaceutical Package Blister Leak Tester
Medical and Pharmaceutical Package Blister Leak Tester
Product Code : MFY-01
Brand Name : Labthink
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price Range
  • 2000 - 20000 USD ($)
Product Specifications
  • Type
  • Electronic
Product Description

MFY-01  Medical and Pharmaceutical Package Blister Leak Tester    is designed for gross leak test of packages for food, drugs, medical instruments, daily chemical products, cars, electronic components, stationeries and other industrial products.

Principle:

Firstly submerge the specimen in the water within the vacuum chamber, and then evacuate the vacuum chamber to form differential pressure between the inside and outside of specimen. The leakage property could be obtained by observing the steady progression of bubbles from the specimen and how the specimen expands and restores to its original shape after vacuum release.

Standards:

ASTM D3078

Features:

  • The instrument utilizes the digital preset design of vacuum degree and vacuum retention time to ensure the accuracy of test data.
  • Top quality parts and components made by world famous brands are used to ensure reliable overall product performance.
  • Specimens could be tested in the preset vacuum condition by automatic compensation of constant pressure.
  • Professional software supports automatic back flushing and test termination to provide a safe test environment.

Applications:

1. Glass Bottles, Pipes, Cans and Boxes
2. Plastic Bottles, Pipes, Cans and Boxes
3. Metal Bottles, Pipes, Cans and Boxes
4. Paper Plastic Composite Bags and Boxes
5. Electronic Components
6. Medical Instruments
7. Pen Refills

Specifications:

Specifications MFY-01
Vacuum Degree 0 ~ -90 KPa
Accuracy 1% FS
Vacuum Chamber Effective Sizes DIA 270 mm x 210 mm (H) (standard)
DIA 360 mm x 585 mm (H) (optional)
DIA 460 mm x 330 mm (H) (optional)
Note: customization is available for other sizes
Gas Supply Pressure 0.7 MPa (outside of supply scope)
Port Size DIA 6 mm PU Tubing
Instrument Dimension 300 mm (L) x 380 mm (W) x 450 mm (H)
Power Supply AC 220V 50Hz
Net Weight 12 kg

Trade Information
  • FOB Port
  • Jinan
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 7 Days
  • Packaging Details
  • Standard Veneer Case
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, CE
