Food Packages Leak Testing Instrument

Food Packages Leak Testing Instrument
Food Packages Leak Testing Instrument
Product Code : LSSD-01
Brand Name : Labthink
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price Range
  • 2000 - 20000 USD ($)
Product Description
Sealable Pouches Leak Testing Instrument

is professionally applicable to the quantitative determination of seal performance, seal quality, burst pressure, compression resistance, torsion force and joint/disengaging force of flexible packages, aseptic packages, various plastic pilfer-proof closures, flexible tubes, caps and other materials.

Sealable Pouches Leak Testing Instrument conforms to the following standards:

ISO 11607-1, ISO 11607-2, GB/T 10440, GB 18454, GB 19741, GB 17447, ASTM F1140, ASTM F2054, GB/T 17876, GB/T 10004, BB/T 0025, QB/T 1871, YBB 00252005, YBB 00162002

LSSD-01Sealable Pouches Leak Testing Instrument is applicable to the determination of:

Basic Applications

  • Plastic Composite Bags
  • Flexible Tubes
  • Creep Test
  • Creep to Failure Test

Based on the positive pressure method and controlled by micro-computer, with LCD, menu interface and PVC operation panel

Dual test methods of restraint distension and unrestraint distension for customer's free choice

Different test modes of burst, creep, and creep to failure to meet different test requirements

Optional test range, "one key operation" and other intelligent designs support combinations of non-standard test conditions

Specifications

LSSD-01 Sealable Pouches Leak Testing Instrument

Test Range

0~600 KPa; 0~87.0 psi (standard)

0~1.6 MPa; 0~232.1 psi (optional)

Gas Injection Head

10 mm (standard)

4 mm, 1.6 mm (optional)

Gas Supply Pressure

0.4 MPa~0.9 MPa (outside of supply scope)

Port Size

8 mm PU Tubing

Instrument Dimension

300 mm (L) x 310 mm (W) x 180 mm (H)

Pedestal Size

305 mm(L) x 356 mm(W) x 325 mm(H)

Power Supply

AC 220V 50Hz

Net Weight

23 kg



Trade Information
  • FOB Port
  • Jinan
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 7 Days
  • Packaging Details
  • Standard Veneer Case
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, CE
