Films & Foils Pendulum Impact Measuring Instruments

Films & Foils Pendulum Impact Measuring Instruments
Films & Foils Pendulum Impact Measuring Instruments
Send Inquiry
Product Code : FIT-01
Brand Name : Labthink
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price Range
  • 2000 - 20000 USD ($)
Product Specifications
  • Power Supply
  • 220VAC 50Hz / 120VAC 60Hz
  • Dimensions
  • 600 mm (L) x 390 mm (W) x 600 mm (H)
  • Gas Pressure
  • 0.6 MPa
  • Number of Specimens
  • 1
  • Port Size
  • Ф6 mm PU Tubing
  • Specimen Size
  • 100 mm x 100 mm or Ф100 mm
  • Usage
  • pendulum impact testing
  • Capacity
  • 3J
  • Machine Weight
  • 64kg
Product Description
Films & Foils Pendulum Impact Measuring Instruments   is professionally designed for impact resistance test of plastic films, sheeting, composite films, aluminum foils and many others.
  • Adjustable test range and electronic measurement make it possible to perform tests at various test conditions.
  • Pneumatic specimen clamping, pendulum release mechanism and horizontal adjustment system effectively reduce the errors caused by manual operation.
  • Automatic statistics of testing data for clients convenient viewing.
  • The pendulum impact tester is controlled by micro-computer with menu interface, PVC operation panel and large LCD display.
  • Equipped with RS232 port and standard micro printer port which is convenient to the data transmission and PC connection.

The Parameters

Items Specifications
Impact Energy 1 J, 2 J, 3 J (Standard)
Resolution 0.001 J
Specimen Size 100 mm x 100 mm or 100 mm
Energy Analysis Accuracy ±0.5%
Net Weight 65 kg

 Applications:

Films & Foils Pendulum Impact Measuring Instruments   can be used to measure the following materials.

1.Films

2. Foils

3.Paper and Paperboard

4. Extended Test Range

Labthink instruments have been widely used and recognized by more than 6,000 scientific institutional laboratories, inspection organizations, and universities and corporate quality control departments.

Labthink is dedicated to providing professional consulting, testing instruments, support services, and quality assurance solutions for packaging in various fields.

Trade Information
  • FOB Port
  • jinan
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 7 Days
  • Packaging Details
  • Standard Veneer Case
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, CE
