Digital Friction Testing Machines

50000 USD ($)/Set

Get a Price/Quote

Product Details:

Measuring Range 0-100 N
Automation Grade Semi-Automatic
Response Time <1 second
Features Microprocessor-based, digital data output, automatic calculation of static & dynamic friction, user-friendly controls
Max Height Approx. 200 mm sample size
Accuracy 1% of reading
Number of Specimens 1 specimen per test
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Digital Friction Testing Machines Price And Quantity

Minimum Order Quantity 1 Set
Price 50000 USD ($)/Set
Price Range 50000.00 - 100000.00 USD ($)/Set

Digital Friction Testing Machines Product Specifications

Test Stroke 100 mm
Features Microprocessor-based, digital data output, automatic calculation of static & dynamic friction, user-friendly controls
Usage Laboratory & industrial quality control
Automation Grade Semi-Automatic
Measuring Range 0-100 N
Response Time <1 second
Temperature Ambient, 5C to 45C
Port Size Standard (customizable)
Test Width Up to 75 mm
Test Range 0-10 N, 0-50 N, 0-100 N (selectable)
Max Height Approx. 200 mm sample size
Accuracy 1% of reading
Number of Specimens 1 specimen per test
Capacity 10 N / 50 N / 100 N (varies by model)
Power Supply 220V AC, 50 Hz
Operating Voltage 220V AC
Humidity Up to 85% RH (operational)
Test Speed 50 mm/min to 500 mm/min (adjustable)
Display Type Digital LCD display
Equipment Type Digital Friction Testing Machine
Resolution 0.01 N
Interface Type RS232 serial port
Mounting Type Bench-top
Frequency 50 Hz
Control Mode Digital control with microprocessor
Application Measurement of friction coefficient of packaging films, foils, rubber, paper
Machine Weight Approx. 36 kg
Specimen Size Width: Up to 75 mm, Length: up to 200 mm

Product Description

Features

Static and kinetic coefficients of friction can be tested for each specimen
This instrument conforms to multiple standards of ISO, ASTM and GB and the user could select testing methods as required
Test speed could be preset and adjusted by the users as required
Sled of specific weight could be customized
The sliding plane and the sled are treated by degaussing and remanence detection which effectively reduce the system error
Top quality parts and components made by world famous brands are used to ensure reliable overall product performance
The instrument is controlled by micro-computer with LCD display, PVC operation panel and menu interface
Professional operating software support statistical analysis of single specimen, group specimens, superposition analysis of test curves and historical data comparison functions
Equipped with RS232 port and micro printer port which is convenient to the data transmission and PC connection
Supports LystemTM Lab Data Sharing System for uniform and systematic data management

Standards

This instrument conforms to various national and international standards:
ISO 8295, ASTM D1894, TAPPI T816, GB 10006

Applications

Basic Applications
Plastic Films and Sheets Coefficient of static and dynamic friction tests of plastic films and sheets
Paper and Paperboard Coefficient of static and dynamic friction tests of paper and paperboard
Textiles, Non-woven Fabrics and Woven Bags Coefficient of static and dynamic friction tests of textiles, non-woven fabrics and woven bags
Rubber Coefficient of static and dynamic friction tests of rubber products
Aluminum Foils, Aluminum Foil Composite Films, and Metal Products Coefficient of static and dynamic friction tests of aluminum foils, aluminum foil composite films and other metal products
Printing Matters Coefficient of static and dynamic friction tests of printing matters
Extended Applications
Wood and Flooring Coefficient of static and dynamic friction tests of wood and flooring
Photographic Films Coefficient of static and dynamic friction tests of photographic films
Grains Coefficient of static and dynamic friction tests of grains against the metal materials
Hair Coefficient of static and dynamic friction tests of the hairs
Pipes Coefficient of static and dynamic friction tests of pipes
Ball Shaped Materials Coefficient of static and dynamic friction tests of the ball shaped material against even leveled materials
Medical Tubes Coefficient of static and dynamic friction tests of medical tubes and artificial skin
Lacquered Wires Coefficient of static and dynamic friction tests of the lacquered wire against even leveled materials

Technical Specifications

Specifications	MXD-02 Coefficient of Friction Tester
Capacity Range	0 5 N
Accuracy	0.5% FS
Stroke	70 mm, 150 mm
Mass of Sled	200 g (Standard)
Mass of Sled	Sled of specific weight could be customized
Test Speed	100 mm/min, 150 mm/min
Test Speed	Test speed could be adjusted
Environment Condition	Temperature: 232C
Environment Condition	Humidity: 20%RH 70%RH
Power Supply	220VAC 50Hz / 120VAC 60Hz
Instrument Dimension	630 mm (L) x 360 mm (W) x 230 mm (H)
Net Weight	33 kg

Configurations

Standard Configurations: Instrument, Micro Printer and Sled of 200g

Optional Parts: Professional Software, Communication Cable and Customized Sled of 500g

Advanced Digital Control and Data Management

Equipped with a microprocessor-based digital control system, this friction testing machine provides accurate, repeatable results with a rapid response time under one second. The interface supports both USB and RS232 outputs, enabling direct connectivity to PCs for instantaneous data transfer. Accompanying analysis software allows for detailed data logging and reporting. The intuitive LCD digital display and user-friendly controls make operation straightforward for both laboratory and industrial users.

Safety, Compliance, and Versatility in Testing

With features like overload protection, emergency stop, and stainless steel sample holders, this machine prioritizes safety and long-term durability. It complies with ASTM D1894 and ISO 8295 standards for friction measurement, catering to quality control requirements in manufacturing and research labs. The adjustable test range, speed, and selectable capacities (10 N, 50 N, 100 N) enhance its versatility, making it suitable for a wide range of sample types and sizes.

FAQ's of Digital Friction Testing Machines:

Q: How do I calibrate the Digital Friction Testing Machine?

A: The machine features automatic electronic calibration, simplifying the process and ensuring highly accurate results. Simply follow the on-screen instructions provided by the software or control panel to initiate and complete the calibration sequence.

Q: What types of materials can be tested with this machine?

A: This equipment is designed for testing friction properties in materials such as packaging films, foils, rubber, and paper. It's suitable for both laboratory research and industrial quality control applications.

Q: When should the overload protection and emergency stop be used?

A: Overload protection automatically safeguards the machine during excessive load conditions, while the emergency stop can be manually triggered for immediate shutdown in case of unexpected events, ensuring operator safety.

Q: Where is the data output sent and how is it accessed?

A: Test data can be output through USB and RS232 ports for quick connection to a PC. The included data logging and analysis software allows for easy access, review, and export of test results.

Q: What is the process for conducting a friction test?

A: Place the specimen (up to 75mm width, 200mm length) in the stainless steel holder, select the test settings on the digital control panel, and start the test. The microprocessor manages motion and records data automatically, which can then be analyzed using the supplied software.

Q: How does using this machine benefit laboratory and industrial operations?

A: The machine delivers accurate, repeatable friction measurements with fast response and automatic data handling features. Its compliance with international standards and robust safety mechanisms help ensure reliable quality control and efficient workflow.
