Home » Products » Seal and Leak Testers » Package Leak Seal Tester/Leak testing Machine

Package Leak Seal Tester/Leak testing Machine

Package Leak Seal Tester/Leak testing Machine
Package Leak Seal Tester/Leak testing Machine
Product Code : LSSD-01
Brand Name : Labthink
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price Range
  • 2000 - 20000 USD ($)
Product Description
Package Leak Seal Tester/Leak testing Machine is professionally applicable to the quantitative determination of seal performance, seal quality, burst pressure, compression resistance, torsion force and joint/disengaging force of flexible packages, aseptic packages, various plastic pilfer-proof closures, flexible tubes, caps and other materials.

Package Leak Seal Tester/Leak testing Machine conforms to the following standards:
ISO 11607-1, ISO 11607-2, GB/T 10440, GB 18454, GB 19741, GB 17447, ASTM F1140, ASTM F2054, GB/T 17876, GB/T 10004, BB/T 0025, QB/T 1871, YBB 00252005, YBB 00162002

Application:

LSSD-01 Package Leak Seal Tester/Leak testing Machine is applicable to the determination of:

Basic Applications
  • Plastic Composite Bags
  • Flexible Tubes
  • Creep Test
  • Creep to Failure Test

Features:

  • Based on the positive pressure method and controlled by micro-computer, with LCD, menu interface and PVC operation panel
  • Dual test methods of restraint distension and unrestraint distension for customer's free choice
  • Different test modes of burst, creep, and creep to failure to meet different test requirements
  • Optional test range, "one key operation" and other intelligent designs support combinations of non-standard test condition

Specification:

Specifications LSSD-01 Package Leak Seal Tester/Leak testing Machine
Test Range 0~600 KPa; 0~87.0 psi (standard)
0~1.6 MPa; 0~232.1 psi (optional)
Gas Injection Head Φ10 mm (standard)
Φ4 mm, Φ1.6 mm (optional)
Gas Supply Pressure 0.4 MPa~0.9 MPa (outside of supply scope)
Port Size Φ8 mm PU Tubing
Instrument Dimension 300 mm (L) x 310 mm (W) x 180 mm (H)
Pedestal Size 305 mm(L) x 356 mm(W) x 325 mm(H)
Power Supply AC 220V 50Hz
Net Weight 23 kg

Our Customers:

Labthink instruments have been widely used and recognized by more than 6,000 scientific institutional laboratories, inspection organizations, and universities and corporate quality control departments.

Labthink is dedicated to providing professional consulting, testing instruments, support services, and quality assurance solutions for packaging in various fields.

Trade Information
  • FOB Port
  • Jinan
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 7 Days
  • Packaging Details
  • Standard Veneer Case
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, CE
