Organic Gas Transmission Rate Test System

Organic Gas Transmission Rate Test System
Organic Gas Transmission Rate Test System
Send Inquiry
Product Code : OR2/410
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price Range
  • 5000 - 50000 USD ($)
Product Specifications
  • Port Size
  • 1/8 inch PVDF tubing
  • Test Range
  • 0.01 ~ 40 g/m2/d/100ppm
  • Usage
  • Organic Gas Permeability Testing
Product Description

Organic Gas Transmission Rate Test System

OR2/410 is practically valid to the measurable fortitude of organic gas transmission rate of composite films, films, packages and sheeting. The device could weigh and regulate the permanent fragrance presentation of packages for perfumed products, e.g. drinks, food,  cosmetics and tea.

Basic Applications :

Films

  • With plastic films, paper-plastic composite films, plastic composite films, aluminized films, coextruded films, aluminum foil composite films, aluminum foils, and several others

Packages :

  • Together with plastic, paper, rubber, glass and metal packages, paper-plastic composite, e.g. peanut oil packages, Coke bottles, materials, metal three-piece cans, vacuum bags, plastic packages for soft tubes for toothpaste, cosmetic, yogurt cups and jelly.

Features :

  • The instrument is founded on the mixture of equal-pressure technique and chromatography examination technology, and is utilized to examine organic gas transmission degree of sheeting, films, and ended package containers.
  • The system uses professional knowledge of high temperature and anti-condensation drying to safeguard the correctness of test data
  • Gas chromatograph is armed with auto-sampling arrangement and multi-level temperature package to meet expert test requirements
  • The system is regulated by computer and test procedure is automatic
  • Professional operating software mixes intelligent process with multi-function data examination
  • Armed with RS232 port for suitable data transfer
  • Supports LystemTM Lab Data Sharing System for even organization of test outcomes and test reports

Standard Configurations

  • Counting Detector, Mainframe, Chromatography Data Arrangement, Continuous Temperature Control Apparatus, and Round Sample Cutter

Note :

  • The gas source port of the tool is  6mm PU Tubing;
  • Clienteles will want to make for gas supply and distilled water.

Technical Details:

Specifications

Film Test

Test Range

0.01 ~ 40 g/m2 100ppm (standard)

Testable Organic Gases

Organics (e.g. ester, benzene, alcohols, ketones, aldehydes, and ether)

Gas Flow

10 ~ 40 ml/min

Gas Concentration

10 ppm ~ 150 ppm

Temperature Accuracy

+0.1oC

Carrier Gas for Lower Chamber

Greater than 99.999% high purity nitrogen (not in amount scope)

Gas Flow

2 ~ 10 ml/min

Port Size

1/8 inch PVDF tubing

Carrier Gas for Gas Chromatograph

More than 99.999% high purity nitrogen (not in stream scope)

Port Size

 3 mm PTFE tubing

Hydrogen Gas

More than 99.999% high purity hydrogen (not in stream scope)

Port Size

 3 mm PTFE tubing

Air

Dry and oil free

Port Size

 3 mm PTFE tubing

Trade Information
  • FOB Port
  • Jinan
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 7 Days
  • Packaging Details
  • Standard Veneer Case
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, CE
